Stihl FSA 80 CORDLESS BRUSHCUTTER – AK SYSTEM

FSA 80 Cordless Brushcutter: Excellent mowing performance, ideal for home gardens

The STIHL FSA 80 is a battery-powered brushcutter designed for tackling the toughest mowing, cutting and clearing jobs you may face in your home garden. The FSA 80 is battery powered and as such has low noise emissions – so you don’t have to worry about disturbing any neighbours either!

Fitted with a bike handle for comfortable working when cutting tall grass and weeds. The folding clamp makes it quick and easy to adjust the bike handle to the ergonomic position that suits you. The FSA 80 has a powerful brushless EC motor and speed-adjustment on the control handle, which can be set at 2 different speed settings. There is an ECO mode (level 1), for simple tasks such as trimming lawn edges, which results in lower energy consumption for extended battery life. And there is full speed mode (level 2), for mowing thicker grass, which will use more of the battery energy.

The FSA 80 is supplied with a basic harness and the GrassCut 230-2 blade as standard, but can also be fitted with other STIHL cutting tools, such as the AutoCut, TrimCut, DuroCut, PolyCut cutting tools.

Features

The pictures shown are sample photos. The actual appearance of the equipment features and their specific attachment to the product may differ from the pictorial representations, but will have the same functionality.

LOOP HANDLE

MORE FREEDOM OF MOVEMENT IN NARROW SPACES. The loop handle makes work in narrow spacers easier, such as clearing between bushes, shrubs or park benches. The practical handle position allows you to move your tool freely and to guide it easily and precisely, even in confined spaces.

HANGING EYELET

FOR SAFE STORAGE. The tool has an eyelet  allowing you to store your tool safely and compactly.

TOOL-FREE HANDLE ADJUSTMENT

SET THE BIKE HANDLE POSITION. You can individually adjust the ergonomic bike handle (mowing handle) using the central clamping device. Thanks to the tool-free handle adjustment, you do not need any tools for this. The bike handle can be rotated 90 degrees for transport and space-saving storage.

TOOL MONITORING WITH THE SMART CONNECTOR

INTEGRATION INTO STIHL CONNECTED. The tool is compatible with the Smart Connector, meaning it can be integrated into the STIHL connected system. Once you have attached a Smart Connector to the tool, after one-time commissioning it will record the tool’s operating hours and transmit them to the STIHL connected App via Bluetooth. In addition to displaying the operational time, the app also provides an overview of all necessary maintenance, ensuring that you do not overlook important upkeep and that your tool is always in a ready-to-use condition.

EC MOTOR

LOW-MAINTENANCE AND EFFICIENT. Thanks to its compact design, low weight and high efficiency, the EC motor enables you to work in an energy efficient manner. This engine also has a long service life.

Technical details

Rated voltage	36 V
Power	0.8 kW
Battery system	AK
Recommended battery	AK 30
Weight	4.3 kg
Cutting circle diameter	380 mm
IPX Rating	N/A
Battery working time AK 10 (Power level 1)	up to 20 min 1)
Battery working time AK 10 (Power level 2)	10 min 2)
Battery working time AK 20 (Power level 1)	up to 50 min 1)
Battery working time AK 20 (Power level 2)	30 min 2)
Battery working time AK 30 S (Power level 1)	up to 60 min 1)
Battery working time AK 30 S (Power level 2)	40 min 2)
Overall length	178 cm 3)
Sound pressure level	81 dB(A) 4)
Sound power level	94 dB(A) 4)
Vibration level, left	1.9 m/s²
Vibration level, left	3.2 m/s² 5)
Vibration level, right	1.9 m/s² 5)
Vibration level, right	1.3 m/s²

¹⁾With GrassCut blade. Working times are approximate and may vary depending on application²⁾With AutoCut mowing head. Working times are approximate and may vary depending on application³⁾Without cutting attachment⁴⁾K-factor according to DIR 2006/42/EC = 2.5 dB (A)⁵⁾K-factor according to DIR 2006/42/EC = 2m / s ²
